VIAVI CX100 - Handheld Radio Test Set
In a first of its kind form factor, the CX100 provides users with a full-color, easy to use interface, with exceptional operating performance. With advanced features like a 6 GHz frequency range, 1 port VNA for cable and antenna analysis, and remote operation with the VIAVI Mobile Tech app, the CX100 brings field maintenance support to the next level.
Key Features
- Handheld
- Lightweight - 11 lbs
- Rugged - 30G Shock, MILPRF28800F
- 1 MHz - 6 GHz frequency range (Standard)
- CW, FM, and AM Conventional Tests
- RF Input Power Up to 20 Watts (Use Attenuators to Measure > 20 Watts)
- 6 GHz Spectrum Analyzer - 1kHz / Div, Full Span, and Zero Span
- Audio Analyzer - DC to 100kHz
- FM Deviation Meter Accuracy - +/- 1% from 1.5kHz to 3kHz; +/- 2% Full Range
- 1 port Vector Network Analyzer - VSWR, Return Loss, and Distance to Fault
- Bluetooth and Wi-Fi options
- Internal Battery - 3+ Hours
- Full Color, Touch Screen Display
- VIAVI Mobile Tech application for remote use
VIAVI 8800SX Radio Test Set
VIAVI 8800SX Radio Test Set
VIAVI 8800SX Radio Test Set
Radio Test Solution for the bench and for the field; testing AM, FM, P25, DMR (MOTOTRBO), NXDN, PTC (Railway), dPMR, and TETRA. Automated Test & Alignment for multiple radio families. VSWR / Return Loss Testing; Accurate Power Meter to 500 Watts; Lighweight and large, easy to view display.
Auto-Test & Alignment
VIAVI 8800SX Radio Test Set
VIAVI 8800SX Radio Test Set
Accurate, ultra-fast, and OEM approved Automated Test and Alignment of multiple portable and mobile radio families from Motorola, Kenwood, Harris, BK Radio, Hytera, ICOM, and more.
In-Building Coverage Tests
In-Building Coverage Tests
In-Building Coverage Tests
NEON Signal Mapper automates the
geo-referencing cloud storage, and 3D visualization of LMR test data for technicians who use VIAVI AvComm radio test equipment to record and analyze two-way radio signals inside buildings and outdoors.
Outdoor Drive Tests
In-Building Coverage Tests
In-Building Coverage Tests
STI Field Test 7 captures DMR or P-25 phase 1 or 2 signal analytics. Analog communications systems can be tested for Audio Quality. Field Test 7 can have drive test functionality as well as complete measurement automation, data reduction and reporting capabilities. Field Test 7 comes with a USB drive, GPS receiver antenna, manual and street data.
